BHP2A0D10C0U0|SAE-A Gear Pump with 5/8" Keyed Shaft, Clockwise Rotation, 10cc

Price:

213.33 $
  2. Shop
  3. BHP2A0D10C0U0|SAE-A Gear Pump with 5/8" Keyed Shaft, Clockwise Rotation, 10cc
11186046|200 cc 4 bolt 1 in keyed shaft hydraulic motor with ORB ports ( must order 5 pieces per PO )
11186046|200 cc 4 bolt 1 in keyed shaft hydraulic motor with ORB ports ( must order 5 pieces per PO )
510.50 $
510.50 $
101-1-280-F|280CC steering unit - open center
101-1-280-F|280CC steering unit - open center
279.57 $
279.57 $

BHP2A0D10C0U0|SAE-A Gear Pump with 5/8" Keyed Shaft, Clockwise Rotation, 10cc

https://www.arrowfluiddynamics.com/web/image/product.template/71186/image_1920?unique=bfbd7fe

213.33 $ 213.33 CAD 213.33 $ VAT Excluded

$ 213.33 VAT Excluded

Not Available For Sale

  • Dimensions
  • Displacement
  • Input Shaft Type
  • Inlet Port Size
  • Outlet Port Size
  • Rotation
  • Mounting Type
  • Port Location
  • Max Speed
  • Min Speed
  • Max Pressure (Continuous) Bar
  • Max Pressure (Inter.) Bar
  • Max Pressure (Peak) Bar

This combination does not exist.

Contact Us
SKU: :
BHP2A0D10C0U0
Share :
Terms and Conditions :
100% original guarantee
Return within 30days
Fast delivery
Dimensions
Dimensions 5.125 x 4.5 x 5.25 in
Uncategorized
Displacement 10cc
Input Shaft Type 5/8" Keyed Shaft
Inlet Port Size 1 1/16-12 UNF
Outlet Port Size 7/8-14 UNF
Rotation Clockwise
Mounting Type 2-Bolt SAE A Flange
Port Location Side Ports
Max Speed 3000
Min Speed 500
Max Pressure (Continuous) Bar 270 bar
Max Pressure (Inter.) Bar 285 bar
Max Pressure (Peak) Bar 300 bar
​
